Automated Optical Inspection (AOI) TR7700 SIII Ultra SMT AOI Machine
| Place of Origin | China |
|---|---|
| Brand Name | TRI |
| Certification | CE,ISO |
| Model Number | TR7700 SIII Ultra |
| Minimum Order Quantity | 1 |
| Price | Negotiation |
| Packaging Details | Standard Packaging |
| Delivery Time | 1-2days |
| Payment Terms | L/C, D/A, D/P |
| Supply Ability | Long-time |
Contact me for free samples and coupons.
WhatsAPP:0086 18588475571
Wechat: 0086 18588475571
skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Condition | New/used | Speed | High-Speed |
|---|---|---|---|
| Quality | Excellent | Part Number | TR7700 SIII Ultra |
| Stock | With Stocks | Precision | High-precision |
| Highlight | Automated Optical Inspection AOI Machine,TR7700 SIII SMT AOI Machine,Ultra SMT AOI Machine |
||
Product Description
Automated Optical Inspection (AOI) TR7700 SIII Ultra SMT AOI Machine.
Specification:
| Optical System | |
| Imaging Method | Dynamic Imaging |
| Top Camera | 4 MP / 9 MP / 12 MP High Speed Color Camera |
| Angle Camera | N/A |
| Imaging Resolution | 5.5 µm, 6 µm , 10 µm , 15 µm (factory setting) |
| Lighting | Multi-phase RGB+W LED |
| 3D Technology | 3D Laser Sensor (Optional) |
| Max. 3D Range | N/A |
| Inspection Performance | |
| Imaging Speed | 4 MP@ 10 μm: up to 60 cm²/sec |
| 4 MP@ 15 μm: up to 120 cm²/sec | |
| 9 MP@ 10 μm: up to 80 cm²/sec | |
| 12 MP@ 5.5 μm: up to 32 cm²/sec | |
| 12 MP@ 6 μm: up to 37 cm²/sec | |
| Motion Table & Control | |
| X-Axis Control | Ballscrew + AC Servo with Motion Controller |
| Y-Axis Control | Ballscrew + AC Servo with Motion Controller |
| Z-Axis Control | Ballscrew + AC Servo with Motion Controller |
| X-Y Axis Resolution | 1 µm |
| Board Handling | |
| Max PCB Size | TR7700 SIII Ultra: 510 x 460 mm |
| TR7700 SIII Ultra DL: 510 x 310 mm x 2 lanes, 510 x 590 mm x 1 lane | |
| PCB Thickness | 0.6-5 mm |
| Max PCB Weight | 3 kg. Optional: 5 kg |
| Top Clearance | 25 mm. Optional: 48 mm |
| Bottom Clearance | 40 mm |
| Edge Clearance | 3 mm. Optional: 4 mm / 5 mm |
| Conveyor | Inline Height: 880 – 920 mm |
| * Optional: 940-965 mm (SMEMA compatible) | |
| Inspection Functions | |
| Component | Missing |
| Tombstoning | |
| Billboarding | |
| Polarity | |
| Rotation | |
| Shift | |
| Wrong Marking (OCV) | |
| Defective | |
| Upside Down | |
| Extra Component | |
| Foreign Material | |
| Solder | Excess Solder |
| Insufficient Solder | |
| Bridging | |
| Through-hole Pins | |
| Lifted Lead | |
| Golden Finger | |
| Scratch/Contamination | |
| Dimensions | |
| WxDxH | TR7700 SIII Ultra: 1100 x 1720 x 1710 mm |
| TR7700 SIII Ultra DL: 1365 x 1720 x 1710 mm | |
| Note: Not including signal tower, signal tower height 515 mm | |
| Weight | TR7700 SIII Ultra: 940 kg |
| TR7700 SIII Ultra DL: 960 kg |
Other machine:
| TR7007D Plus |
| TR7007M SII Plus |
| TR7700 SII |
| TR7007 SII |
| TR7007Q SII |
| TR7007 SIII |
| TR7007Q Plus |
| TR7700QH SII |
| TR7500QE Plus |
| TR7700QB SII |
| TR7700 SIII Ultra |
| TR7700QC SII |
| TR7700 SIII DT |
TR7700 SIII Ultra picture:
