| 00119862-01 |
The Adapter Kit SIPLACE D1 P&P Head is necessary to upgrade a Siplace D1 machine with only a Collect & Place Head to a SIPLACE D1 with an additional P&P Head. After the upgrade a wider component range could be achieved, in detail for larger and higher components. For more details regarding wider component range and other technical points, please see the actual specification of the SIPLACE D1. This adapter kit includes the Pick and Place Module, Nozzle changer P &P which includes 2 dual magazines for standard nozzles and 1 magazine for special nozzles, stationary Component Camera (Type 36), Servo cards, electrical and pneumatic connections, small parts and a technical manual. The retrofit time for the machine of the hardware parts will be approx. 4 hours (excluding additional effort on programming in SIPLACE Pro). |
| 00119863-01 |
The Adapter Kit SIPLACE D1 C&P 6 Head is necessary to upgrade a Siplace D1 machine with only a Pick & Place Head to a SIPLACE D1 with an additional 6 Segment Collect & Place Head. After the upgrade a wider component range could be archived and due to the Collect & Place principle also a higher placement rate with smaller components. For more details regarding higher performance and wider component range, please see the specification of the SIPLACE D1. This adapter kit includes the 6 Segment Collect & Place Head, 12 Sleeves, Component Camera (Type 29), Servo cards, electrical and pneumatic connections, small parts and a technical manual. If required, the automatic nozzle changer for the 6 Segment Collect & Place head has to be ordered separately (Item No. 119866). The retrofit time for the machine of the hardware parts will be approx. 4 hours (excluding additional effort on programming in SIPLACE Pro). |
| 00119864-01 |
The Adapter Kit SIPLACE D1 C&P 12 Head is necessary to upgrade a Siplace D1 machine with only a Pick & Place Head to a SIPLACE D1 with an additional 12 Segment Collect & Place Head. After the upgrade a wider component range could be achieved and due to the Collect & Place principle also a higher placement rate with smaller components. For more details regarding higher performance and wider component range, please see the specification of the SIPLACE D1. This adapter kit includes the 12 Segment Collect & Place Head, 12 Sleeves, Standard Component Camera (Type 28), Servo cards, electrical and pneumatic connections, small parts and a technical manual. If required, the automatic nozzle changer for the 12 Segment Collect & Place head has to be ordered separately (Item No. 119865). The retrofit time for the machine of the hardware parts will be approx. 4 hours (excluding additional effort on programming in SIPLACE Pro). |
| 00119920S01 |
Package for placement of 01005 components (size 0.4mm x 0.2mm). Suitable for the SIPLACE D4/D2/D1 equipped with the 12 Collect & Place Head (DLM3). The component range will be from 01005 up to the maximum of 16mm x 16mm. The package includes: 1 x High resolution camera Type 38 (exchange against standard component camera. The standard component camera is then not part of the delivery), 12 x Nozzle 905, 3 x Low Force Sleeves, 1 x Assembly instruction. Also included are shims for the component tables of the SIPLACE D4. In addition the tape feeder module 3x8mm 01005 Comp. (Item number:176100) is necessary for 01005 feeding and has to be ordered separately. Additional Low Force Sleeves could also be ordered (Item number: 03054107-xx). For additional 0201 placement, a component sensor (item number: 118021) is mandatory. The price for this 01005 package is only valid in combination with a new D-Series Machine (D4/D2/D1). System requirement: Station Software from 604 and SIPLACE Pro from Version 5.0. |
| 00119977-01 |
PCI memory card for storing data for the function recovery placement in SIPLACE X-series. One card per machine is required. With the function recovery placement the placement of a PCB inside SIPLACE X4i can be continued after power or system failure. |
| 00119992S01 |
Option Smart Pin Support is required once for the SX1/2 single and dual line per SX1/2. Prerequisit is transport type V2. This option includes the pin picker and depending on table position and nozzle changer configuration either a magzine L10 (119996) or Q10(119997). Per transport lane 5 pins (119995) are included. Considering the cofiguration list additional magazins and pins can be ordered. |
| 00119995S01 |
5 Standard Support Pins (type101) for the option Smart Pin Support. Dependant on the magazine type 10 pins (L10,Q10) or 5 pins (W5) can be accommodated. |
| 00120040-01 |
ADJUSTING GAUGE COMPONENT CARRIAGE FOR HS180 |
| 00140113-01 |
Solution to verify SIPLACE X-feeders on accuracy and functionality and also to perform maintenance and simple parts replacement. The package contains X-Feeder Care Station for electronic test of the main feeder functionality, User manual, Feeder Service Manual, specific tools. This offering in combination with a Feeder Care Training enables customers to gain all expertise to ensure that SIPLACE X-feeders are capable for production. |
| 00141070S02 |
SIPLACE Tape feeder for 1 x 88mm tape, with electric drive and cover tape storage bin, 4mm to 96mm feed increments, for SIPLACE F and HF/X/D-Series. 3.5 feeder locations required per module. |
| 00141088S01 |
Tape feeder module 3x8mm SL SIPLACE |
| 00141092S05 |
Feeder module for 1 x 12mm or 1 x 16mm tape (reconfigurable), 4mm - 16mm feeding pitch with motorized drive and integrated cover foil removal for SIPLACE 80S-15/20/F/F4, 1 feeder location required per module From SW version 402.03 ( S-20/F4) or 9.02 |
| 00141093S05 |
Feeder module for 1 x 24mm or 1 x 32mm tape (reconfigurable), 4 - 32mm feeding pitch with motorized drive and inte- grated cover foil removal for SIPLACE 80 S15/20/F/F4/F5/S23HM, 1 feeder locations required per module. From SW version 402.03 or 9.02 |
| 00141094S05 |
Feeder module for 1 x 44mm tape 4 - 44mm feeding pitch with mo- torized drive and integrated cover foil removal for SIPLACE 80F/F4. 2 feeder locations re- quired per module. From SW version 402.03 or 9.02 |
| 00141095S05 |
Feeder module for 1 x 56mm tape 4 - 56mm feeding pitch with motorized drive and integrated cover foil removal for SIPLACE 80F/F4 2,5 feeder locations required per module. From SW version 402.03 or 9.02 |
| 00141097S05 |
Feeder module for 1x72mm S-tape 4 - 72mm feeding pitch with mo- torized drive and integrated cover foil removal for SIPLACE 80 F/F4/F5 |
| 00141117S02 |
Feeder with tape return mechanism for tantalum capacitor types E for 1 x 12mm tape with electric motor and cover foil pick-up, 4-16mm feeder pitch, for SIPLACE HS-50, SIPLACE 80 S-15/S-20/S-23 and SIPLACE 80 F/F4/F5 HM. |
| 00141118S02 |
Feeder with tape return mechanism for tantalum capacitor types C/D for 1 x 12mm tape with electric motor and cover foil pick-up, 4-16mm feeder pitch, for SIPLACE HS-50, SIPLACE 80 S-15/S-20/S-23 and SIPLACE 80 F/F4/F5 HM. |
| 00141193S01 |
Feeder module for 1 x 24mm or 1 x 32mm tape (configurable),up to 25mm tape height,4mm/40mm feeding pitch, with motorized drive and integrated cover foil removal,for SIPLACE. 1,5 feeder locations required per module. From SW version V402.03. |
| 00141194S01 |
Feeder module for 1 x 44mm tape,up to 25mm tape height,4mm/52mm feeding pitch, with motorized drive and integrated cover foil removal,for SIPLACE F and HF/X-Series. 2 feeder locations required per module. From SW version V402.03 or V9.02. |
| 00141195S01 |
Feeder module for 1 x 56mm tape,up to 25mm tape height,4mm/68mm feeding pitch, with motorized drive and integrated cover foil removal,for SIPLACE F and HF/X-Series. 2,5 feeder locations required per module. From SW version V402.03 or V9.02. |
| 00141255-01 |
Power Supply for SIPLACE Feeder Modules with S-interface (not for X-feeders). |
| 00141269S02 |
Tape Feeder Module 2x8mm X |
| 00141270S04 |
Tape Feeder Module 8mm X for 1 x 8mm component tape, motorized drive, cover foil storage and unique feeder ID for SIPLACE X-Series. Feeder pitch sent automatically from the programming system or set at feeder control panel. |
| 00141271S04 |
Tape Feeder Module 12mm X |
| 00141272S06 |
Tape Feeder Module 16mm X |
| 00141273S06 |
Tape Feeder Module 24mm X for 1 x 24mm component tape, motorized drive, cover foil storage and unique feeder ID for SIPLACE X-Series. Feeder pitch sent automatically from the programming system or set at feeder control panel. |
| 00141274S06 |
Tape Feeder Module 32mm X for 1 x 32mm component tape, motorized drive, cover foil storage and unique feeder ID for SIPLACE X-Series. Feeder pitch sent automatically from the programming system or set at feeder control panel. |
| 00141275S06 |
Tape Feeder Module 44mm X for 1 x 44mm component tape, motorized drive, cover foil storage and unique feeder ID for SIPLACE X-Series. Feeder pitch sent automatically from the programming system or set at feeder control panel. |
| 00141276S06 |
Tape Feeder Module 56mm X for 1 x 56mm component tape, motorized drive, cover foil storage and unique feeder ID for SIPLACE X-Series. Feeder pitch sent automatically from the programming system or set at feeder control panel. |
| 00141289S02 |
Tape Feeder Mod. 2x8mmX w. Splice Sensor |
| 00141290S06 |
Tape Feeder Mod. 8mm X w. Splice Sensor |
| 00141291S05 |
Tape Feeder Module 12mm X with Splice Sensor for 1 x 12mm component tape, motorized drive, cover foil storage and unique feeder ID for SIPLACE X-Series. Feeder pitch sent automatically from the programming system or set at feeder control panel. Attention: Functionality of the splice sensor is only available with software and hardware upgrade/exchange planned with SW 605 (Q-Package 2). Until this time the function Splice Detection is deactivated and is therefore no acceptance criteria. |
| 00141292S06 |
Tape Feeder Mod. 16mm X w. Splice Sensor. |
| 00141293S06 |
Tape Feeder Mod. 24mm X w. Splice Sensor. |
| 00141294S06 |
Tape Feeder Mod. 32mm X w. Splice Sensor. |
| 00141295S06 |
Tape Feeder Mod. 44mm X w. Splice Sensor. |
| 00141296S06 |
Tape Feeder Mod. 56mm X w. Splice Sensor. |
| 00141297S06 |
Tape Feeder Mod. 72mm X w. Splice Sensor. |
| 00141298S06 |
Tape Feeder Mod. 88mm X w. Splice Sensor. |
| 00141371S03 |
SIPLACE SmartFeeder 12mm X |
| 00141372S03 |
SIPLACE SmartFeeder 16mm X |
| 00141391S03 |
SIPLACE SmartFeeder 12mm X Splice Sensor |
| 00141392S03 |
SIPLACE SmartFeeder 16mm X Splice Sensor |
| 00142025S01 |
Linear vibration feeder module for components in stick maga- zines. Magazine width 4,5mm 9.5mm, 15mm, 30mm - SIPLACE 80S / 80F - MS/SP/HS With SIPLACE machines item no. 116140 required, with MS-72/90/128/SP/HS machines and integrated potentiometer item no 142022 required, with MS-102/132 without integrated potentio- meter item no 142023 required, Magazines are not included 1 feeder location required per module |
| 00142031S04 |
Feeder module for components in stick magazines. Magazine width 4,5mm, 9,5mm, 15mm and 30mm. Electrically driven with electronic control for all SIPLACE 80 S and 80 F types. Use only with feeder change over table software version 003.005, Item-No. 328713-05. |
| 00142179-01 |
M-MAG-15MM;SOL 16/20;IC DIL 4/6/8 |
| 00142311-01 |
Module specific special magazine type D1/122 price category C |
| 00142318S06 |
Basement for Bulk-Case-Feeder for SIPLACE 80 S15/S20, SIPLACE S23HM, SIPLACE 80 F/F4/F5 |
| 00142322S03 |
Feeding rail Chip 0603, 0,80mm high for base bulk case feeder SIPLACE, Item no. 142318 Channel width : 0,99mm + 0,05, Channel height: 0,96mm + 0,05. |
