PCB printed circuit board black oil board PCB Board Assembly FR-4 PCB

Place of Origin ShenZhen
Brand Name PY
Certification ISO9001
Model Number Multilayer PCB
Minimum Order Quantity 1pcs
Price Negotiation
Packaging Details Box packing
Delivery Time 1-3 days
Payment Terms L/C, T/T, PAYPAL
Supply Ability Ten thousand square meters per month

Contact me for free samples and coupons.

WhatsAPP:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Color Green,Red,Black,Yellow,White,Blue Number Of Plies 2-4-6-8-10-12-16-20-22-28 Layer
Copper Thickness 1-4oz Base Material FR-4 ,Rogers , Aluminum ,Hight TG
Board Thickness 0.6~1.0~1.2~1.6~2.0~2.5~3.0~3.2mm Place Of Origin Guangdong, China (Mainland)
Surface Finishing HASL(lead Free) / Immersion Gold /osp / Immersion Tin/Immersion Silver Min. Hole Size 3mil
Service OEM Services Provided,PCB/Components Sourcing/Soldering/Programming/Testing..,One-stop Turnkey Service,One Stop Turnkey Service,PCBA Surface Finishing HASL,ENIG,OSP,HASL Lead Free,spray Tin
Application Electronics Device,ru 94v0 Pcb Printed Circuit Board,Consumer Electronics,rigid Fpc,mobile Usb Charger
Highlight

FR4 Printed Circuit Board

,

Rigid Flex PCB Board

Leave a Message
Product Description

Applications
Communications
Traditional telecommunication equipment, FTTP, VOIP, multimedia services, data networking and IT infrastructure products, wireless infrastructure products, power amplifiers, splitters and combiners, high power transistors, etc.
Computer Peripherals
High end printers, cable modem, wireless routers, IP telephones, consumer and office products, banking system etc.
Consumer
Computers, televisions, cameras, digital video recorders (DVR), handheld products, LED, etc.
Automotive
Passenger safety systems, engine control systems, air bags, traction control products, etc.
High End Computing and Storage
High performance computer and server, mainframe system and storage equipment, memory, etc.
Industry
Power supply, main control panel, monitor, CCTV products,automotive control equipment, industry robot, access control products etc
Medical
Magnetic resonance imaging (MRI), computed tomography (CT), emergency response defibrillation units, patient monitoring, implantable devices, robotic surgery systems,
biometrics and diagnostic equipment, etc.
Military
Satellite, radar, airplane, control unit, communication equipment .etc.
Test & Measurement
Power meters, electricity tester, thermal tester, light tester, network tester, gas and oil tester, infrared products, semi-conductor test equipment, DUT and probe cards, wafer inspection systems, etc.

Capability

categoryprojectDescription
Base Materialfr-4 ,PTFE ,PolyimideOrdinary Tg, medium Tg, high Tg, halogen free, Low Dk, Low loss, high CTI, PTFE
LAYERRigid PCB1-32LAYER



 fpc PCB0-10LAYER
Rigid -Flexible PCB2-18LAYER
Board ThicknessRigid PCB0.4-6.0MM
fpc PCB0.05-0.36MM
Rigid -Flexible PCB0.4-6.0MM
Copper Thicknessinner layer0.5-8.0 OZ
outer layer0.5-8.0 OZ
Surface FinishingHasl0.3-1.0um
Immersion Gold0.025-0.1um
OSP0.2-0.6um
Immersion tin0.8-1.2um
Solder mask colorouter layerGreen,black,white,blue,yellow,red
Character colorouter layerwhite ,black, yellow
Min. Line Widthinner layer0.05/0.05MM
outer layer0.05/0.05MM
Min. Line Spacinginner layer0.05/0.05MM
outer layer0.05/0.05MM
Drill HoleMax Diling dameter6.5MM
Min Diling Diameter0.1mm
MinSlot0.60MM
Drilig tolerancePTH:+/-0.075mm NPTH:+/-0.05mm
Slot tolerancePTH:+/-0.10mm NPTH:+/-0.05mm
Board SizeRigid PCB800*2000MM
fpc PCB200*800MM
Rigid -Flexible PCB200*500MM
Drill Aspect RatioMechanical hole12.0:1.0
blind hole1.0:1.0
Solder mask bridgegreen oil0.08MM
white,blue,yellow,red0.1MM
black oil0.12MM
Bow and TwistRigid PCB0.5-0.75%
core thicknessRigid PCB0.075MM (excluding copper)
Resin plug holehole size0.2-0.35mm
Carbon oilthickness10um(min)
V - cutRigid PCB30 45 60 (Tolerance: + / - 5 degrees)
impedance50-120 ohmTolerance: + / - 10 %
PP typeCommonly used1080,2116,7628 ,106

Advantages
1. PCB factory directly
2. Comprehensive quality control system
3. Competitive price
4. Quick turn delivery time from 24hours.
5. Certificates (ISO/UL E354810/RoHS)
6.10 years experience in exporting service
7. No MOQ/MOV.
8. High quality. Strict through the AOI(Automated Optical Inspection), QA/QC, flying porbe ,Etesting, etc
