Fr-4 Tg170 Fr4 Printed Circuit Board , Double Side Printed Board Assembly With Hasl

Fr-4 Tg170 Fr4 Printed Circuit Board , Double Side Printed Board Assembly With Hasl

Fr-4 Tg170 Fr4 Printed Circuit Board , Double Side Printed Board Assembly With Hasl

Product Details:

Place of Origin: Guangdong, China (Mainland)
Brand Name: py
Certification: UL RoHs ISO9001
Model Number: double side pcb

Payment & Shipping Terms:

Minimum Order Quantity: 5 pcs
Price: Negotiable
Packaging Details: box
Delivery Time: 5-10 work days
Payment Terms: L/C, T/T, paypal
Supply Ability: Ten thousand square meters/month
Contact Now
Detailed Product Description
Base Material: FR-4 ,Rogers , Aluminum ,Hight TG Board Thickness: 0.6~1.0~1.2~1.6~2.0~2.5~3.0~3.2mm
Number Of Layers: 2-4-6-8-10-12-16-20--22-28Layer Urface Finishing: HASL(lead Free) / Immersion Gold /osp / Immersion Tin/Immersion Silver
Copper Thickness: 1-4oz Min. Hole Size: 4mil
Min. Line Width/Spacing: 3/3mil Solder Mask Color: Green,black,white,blue,yellow,red
Character Color: White ,black, Yellow Place Of Origin: Guangdong, China (Mainland)

Product Description:
Base Material: FR-4 ,Rogers , Aluminum , Flexible ,hight tg, CEM-3 ,Ceramic
Board Thickness:0.6~1.0~1.2~1.6~2.0~2.5~3.0~3.2mm
Number of Layers: 2-4-6-8-10-12-16-20-28Layer
Price: Negotiable
Min. Line Width:3 Mil
Min. Line Spacing:3 Mil
Surface Finishing:HASL(lead Free) / Immersion Gold /osp / Immersion tin/Immersion silver
Copper Thickness:1~3 Oz
Min. Hole Size: 4 Mil
Solder mask color:Green,black,white,blue,yellow,red
Character color:white ,black, yellow
Place of Origin: Guangdong, China (Mainland)
Supply Ability:Ten thousand square meters/month





Introduction


Double sided circuit board means has a double-sided copper, and metallized holes, that is double-sided copper, and copper are holes inside

Both sides have double wiring board, but to use the wire on both sides. Both sides must be in the room with appropriate electrical connections. "Bridge" between this circuit called vias. Guide hole in the PCB, metal filled or coated with holes, which can be connected to the conductors on both sides. Because dual-panel area twice as big than the single panel, double panel to solve the single-panel wiring staggered because of difficulty (can be turned to the other side of the hole), it is more suitable for use in more complex than single-panel circuit.





Advantages


Compared with single-board: wiring convenient, simple, labor-intensive wiring smaller, shorter line length.





Double Circuit Board Design Steps



1. Prepare circuit schematics

2. Create a new file and loaded PCB component package library

3, planning board

4, into the network table and components

5, automatic layout components

6, layout adjustment

7, the network density analysis

8, wiring rules set

9, automatic routing

10, manually adjust the wiring
