Multilayer Fr4 Tg170 PCB Printed Circuit Board 10 Layer 1.2mm Thickness
Capability
| 1 |
High precision prototype |
PCB bulk production |
|
2
|
1-28 layers |
10 layers |
| 3 |
3mil |
4mil |
| 4 |
0.15mm |
0.2mm |
| 5 |
Aspect Ration≤13:1 |
Aspect Ration≤13:1 |
| 6 |
2 layers:0.2mm;4 layers:0.35mm;6 layers:0.55mm;8 layers:0.7mm;10 layers:0.9mm |
10 layers |
| 7 |
Immersion Gold:Au,1—8u”
Gold finger:Au,1—150u”
Gold Plated:Au,1—150u”
Nickel Plated :50—500u” |
Immersion Gold:Au,1—8u” |
| 8 |
Board thickness≤1.0mm:+/-0.1mm
1.0mm<Board thickness≤2.0mm:+/-10%
Board thickness>2.0mm:+/-8% |
Board thickness≤1.0mm:+/-0.1mm |
| 9 |
≤100mm:+/-0.1mm
100< ≤300mm:+/-0.15mm
>300mm:+/-0.2mm |
≤100mm:+/-0.1mm |
| 10 |
±10% |
±10% |
The importance of
It is an important electronic component, is the support of electronic components.
Printed circuit boards are not common end products, and there is a bit of confusion in the definition of the name.
For example: the personal computer with the motherboard, called the motherboard, and can not be directly called the circuit board, although the motherboard has the existence of circuit boards, but
They are not the same, so they are related but not the same when evaluating industries.
Another example: because there are integrated circuit parts loaded on the circuit board, so the news media called it IC board, but it is not the same as
Printed circuit boards.We usually say the printed circuit board refers to the bare board - that is, no components on the circuit board.
Five, classification,
Classification according to the number of circuit layers of PCB PCB: PCB PCB is divided into single panel, double panel and multi-layer board.Common multilayer board a
Generally for 4 layers of plate or 6 layers of plate, complex multilayer plate up to dozens of layers.
Ping You Industrial Co.,Ltd
Ping You Industrial Co.,Ltd is a professional and reliable one-stop PCB solutions provider for customers specialized in manufacturing quick turn prototypes and small volumes.Topfast is responsible for overseas business development.With high quality and on-time delivery products we won the market's wide acclaim. We will continue to focus on customer satisfaction, along with "high quality "and "fast delivery", we will become a PCB service provider worthy of customer trust.
