HASL Printed Circuit Board multilayer Rigid FR4 HDI PCB Board

Place of Origin ShenZhen
Brand Name PY
Certification ISO9001
Model Number Multilayer PCB
Minimum Order Quantity 1PCS
Price 0.1-1USD
Packaging Details High quality carton packing, high quality vacuum packing,
Delivery Time 5-10 work days
Payment Terms T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability Ten thousand square meters per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Color Green, Number Of Plies 2-4-6 Layer
Copper Thickness 2oz Base Material FR-4
Board Thickness 0.6~1.0~1.2mm Place Of Origin Guangdong, China (Mainland)
Surface Finishing HASL(lead Free) Min. Hole Size 3mil
High Light

HASL Printed Circuit Board

,

multilayer Rigid PCB

,

FR4 HDI Printed Circuit Board

Leave a Message
Product Description

HASL Printed Circuit Board multilayer Rigid FR4 HDI PCB Board



Capability



category project Description
Base Material fr-4  Ordinary Tg,
LAYER Rigid PCB 4LAYER



   PCB 0-10LAYER
Rigid PCB 2-18LAYER
Board Thickness Rigid PCB 0.6MM
0.08 0.08MM
Rigid  PCB 0.4-6.0MM
Copper Thickness inner layer 2 OZ
outer layer 2 OZ
Surface Finishing Hasl 0.6um
Immersion Gold 0.6um
OSP 0.2um
Immersion tin 0.8um
Solder mask color outer layer Green
Character color outer layer white ,black, yellow
Min. Line Width inner layer 0.05MM
outer layer 0.05MM
Min. Line Spacing inner layer 0.05MM
outer layer 0.05MM
Drill Hole Max Diling dameter 6.5MM
Min Diling Diameter 0.1mm
MinSlot 0.60MM
Drilig tolerance PTH:+/-0.075mm NPTH:+/-0.05mm
Slot tolerance PTH:+/-0.10mm NPTH:+/-0.05mm
Board Size Rigid PCB 800*2000MM
fpc PCB 200*800MM
Rigid -Flexible PCB 200*500MM
Drill Aspect Ratio Mechanical hole 12.0:1.0
blind hole 1.0:1.0
Solder mask bridge green oil 0.08MM
white,blue,yellow,red 0.1MM
black oil 0.12MM
Bow and Twist Rigid PCB 0.5-0.75%
core thickness Rigid PCB 0.075MM (excluding copper)
Resin plug hole hole size 0.2-0.35mm
Carbon oil thickness 10um(min)
V - cut Rigid PCB 30 45 60 (Tolerance: + / - 5 degrees)
impedance 50-120 ohm Tolerance: + / - 10 %
PP type Commonly used 1080,2116,7628 ,106



The basic composition of



PCB circuit board (PCB), also known as printed circuit boards, printed circuit board, or PCB, English abbreviation PCB (printed circuit board) or the PWB (printed wiring board), insulation board as base material, cut into a certain size, with at least one conductive graphics, and cloth have a hole (such as component hole, fastening hole, hole metallization, etc.), is used to replace previous device electronic components of the chassis, and realize the connection between the electronic components.Because the board is made by electronic printing, it is called "printed circuit board".The customary term "printed circuit board" is not accurate, because there are no "printed components" on the printed board, only the wiring.


Second, the basic composition
At present, the circuit board is mainly composed of the following:
1. Circuit and Pattern: The circuit is used as a tool to conduct between the original parts. In the design, a large copper surface will be additionally designed as the grounding and power layer.The lines and drawings were made at the same time.
2.Dielectric layer (Dielectric) : used to maintain the insulation between the lines and the layers, also known as the substrate.
3. hole (Through hole/via) : Through hole can make more than two levels of lines Through each other, the larger Through hole is used as part plug-in, in addition to the non-through hole (NPTH) is usually used as a surface mount positioning, fixing screws used during assembly.
4.Solder resistant ink (Solder resistant /Solder Mask) : not all copper surface to eat tin parts, so non-tin eating area, will print a layer of isolation copper surface to eat tin material (usually epoxy resin), to avoid short circuit between non-tin eating tin lines.According to different technology, divided into green oil, red oil, blue oil.

HASL Printed Circuit Board multilayer Rigid FR4 HDI PCB Board 0HASL Printed Circuit Board multilayer Rigid FR4 HDI PCB Board 1

Pingyou Industrial Co., Ltd

Provides the World′s Quickest - PCB Board Design to Loaded Assembly. If getting your design manufactured and to the marketplace first is critical to your success Pingyou Industrial is a great solution. No one beats our New Product Introduction (NPI) and New Product Development (NPD) capabilities. Zhongrun High-tech supports "ANY" or "ALL" of your PCB Board: Design, Layout, Bare Board Fabrication, Assembly, and Complete Box Build needs.
Pingyou Industrial offers the "World′s Quickest" service through our unique and dynamic capabilities. We control the entire process - Idea thru. Finish Product - and have the systems in place to seamlessly process from one step to another. This allows unparalleled cycle time reduction. Pingyou Industrial also eliminates the blame game, as we can handle it all.



HASL Printed Circuit Board multilayer Rigid FR4 HDI PCB Board 2HASL Printed Circuit Board multilayer Rigid FR4 HDI PCB Board 3





RFQ

1. Are you headquarter or branch?
We are Ping you headquarter and factory.



2. Can I ask for samples before placing an order?
Yes, we welcome sample order to test and check quality,Miced samles are acceptable.



3. How to be your overseas agent?
Depends which area you are located in,Every conuntries are different.



4. What need I do if I want to pint my own logo?
First, please send us your logo flie in high resolution, We will make some drafts for your reference to confirm the position and size of your logo.Next we will 1-2 samples for you to check the actual effect.Finally the formal production will start after the sample confrimed .



5. Can you ship the goods to my agent or shipping forwarder in China?
Yes,We can,please kindly contact with your agent in advance and us detailed address.



6. How can you solve the problem if receive the defective goods?
Will check all the products before delivery,Please kindly provide the pictures or video and send back to china or our local agent,After they checking,will replace new or fix free.
