1 Layer Single Side 1oz PCB Printed Circuit Board Black Solder Mask

1 Layer Single Side 1oz PCB Printed Circuit Board Black Solder Mask

1 Layer Single Side 1oz PCB Printed Circuit Board Black Solder Mask
video
1 Layer Single Side 1oz PCB Printed Circuit Board Black Solder Mask
Product Details:
Place of Origin: ShenZhen
Brand Name: PY
Certification: ISO9001
Model Number: PCB
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: USD 0.1-1\PCS
Packaging Details: Vacuum packing, high quality carton
Delivery Time: 5-10 work days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: Ten thousand square meters per month
Contact Now
Detailed Product Description
Color: Black Number Of Plies: 1-2 Layer
Copper Thickness:: 1oz Base Material:: FR4
Board Thickness:: 0.6mm Place Of Origin:: Guangdong, China (Mainland)
High Light:

1oz PCB Printed Circuit Board

,

1oz Single Side PCB

,

Black Solder Mask PCB Printed Circuit Board

1 Layer Single Side 1oz PCB Printed Circuit Board Black Solder Mask





  High precision prototype PCB bulk production
Max Layers 1Layers 1 layers
MIN Line width(mil) 2mil 3mil
MIN Line space(mil) 2mil 3mil
Min via (mechanical drilling) Board thickness≤1.2mm 0.15mm 0.2mm
Board thickness≤2.5mm 0.2mm 0.3mm
Board thickness>2.5mm Aspect Ration≤13:1 Aspect Ration≤13:1
Aspect Ration
Board thickness MAX 6mm 4mm
MIN 2 layers:0.2mm 2 layers:0.2mm
MAX Board size 550*950mm 520x1000mm
Max copper thickness 1oz 1oz
Immersion Gold/
Gold Plated Thickness

Gold Plated:Au,1—150u”

Hole copper thick 25um 1mil 25um 1mil
Tolerance Board thickness thickness≤2.0mm:+/-10%
Board
thickness≤2.0mm:+/-10%
Board thickness>2.0mm:+/-8%
Outline Tolerance ≤300mm:+/-0.15mm


100< ≤300mm:+/-0.15mm

Impedance ±10% ±10%
MIN Solder mask bridge  0.08mm  0.10mm
Plugging Vias capability  0.25mm--0.60mm  0.70mm--1.00mm



What′s critical to getting Your Engineering Design Built ASAP?



1. Get PY team on-board early in the process. We are here to serve you at every step of the process: From product conception thru. Manufacture of your design.



2. Provide complete information necessary to build your Design (See PCB Board Layout Quote Page ). Missing or incorrect information/files can delay your project. At the same time Huafu Fast′s team will assist you to developing any missing or incomplete information for your Design, Layout, or Manufacturing Package.



3. Communication is Key - If your project is time critical - start the communication process early. You will be amazed how working together can positively impact product: Quality, cost, reliability, and cycle time reduction for NPI & NPD and production. It also is a great support to building mature products that need to get done right.



4. If important to you provide a 24 hour contact name and number to keep your project moving in the event of design, manufacturing, and/or documentation questions.



5. Once the PCB Board Layout is complete and sent to you, check it thoroughly and release for fabrication and assembly ASAP.



Applications:



Communications
Traditional telecommunication equipment, FTTP, VOIP, multimedia services, data networking and IT infrastructure products, wireless infrastructure products, power amplifiers, splitters and combiners, high power transistors, etc.
Computer Peripherals
High end printers, cable modem, wireless routers, IP telephones, consumer and office products, banking system etc.
Consumer
Computers, televisions, cameras, digital video recorders (DVR), handheld products, LED, etc.
Automotive
Passenger safety systems, engine control systems, air bags, traction control products, etc.
High End Computing and Storage
High performance computer and server, mainframe system and storage equipment, memory, etc.
Industry

Power supply, main control panel, monitor, CCTV products,automotive control equipment, industry robot, access control products etc
Medical
Magnetic resonance imaging (MRI), computed tomography (CT), emergency response defibrillation units, patient monitoring, implantable devices, robotic surgery systems, biometrics and diagnostic equipment, etc.
Military
Satellite, radar, airplane, control unit, communication equipment .etc.
Test & Measurement
Power meters, electricity tester, thermal tester, light tester, network tester, gas and oil tester, infrared products, semi-conductor test equipment, DUT and probe cards, wafer inspection systems, etc.



Pingyou Industrial Co., Ltd

Provides the World′s Quickest - PCB Board Design to Loaded Assembly. If getting your

design manufactured and to the marketplace first is critical to your success Pingyou

Industrial is a great solution. No one beats our New Product Introduction (NPI) and New

Product Development (NPD) capabilities. Zhongrun High-tech supports "ANY" or "ALL" of

your PCB Board: Design, Layout, Bare Board Fabrication, Assembly, and Complete Box

Build needs.

1 Layer Single Side 1oz PCB Printed Circuit Board Black Solder Mask 0


Pingyou Industrial offers the "World′s Quickest" service through our unique and

dynamic capabilities. We control the entire process - Idea thru. Finish Product - and

have the systems in place to seamlessly process from one step to another. This allows

unparalleled cycle time reduction. Pingyou Industrial also eliminates the blame game,

as we can handle it all.



Single panel features



Because the circuit board on the different network lines can not cross, so the single panel can only be a simple circuit, used for some relatively simple products above.For example, the daily use of the computer keyboard below the circuit board is a single panel, some mouse is a single panel, and some control power supply of the motherboard is a single panel.The single panel has a wide range of uses and will not be obsolete at all.



1 Layer Single Side 1oz PCB Printed Circuit Board Black Solder Mask 1

1 Layer Single Side 1oz PCB Printed Circuit Board Black Solder Mask 2

1 Layer Single Side 1oz PCB Printed Circuit Board Black Solder Mask 3
