Rigid Flex FPC 4oz FR4 Pcb Prototype Board 3.0mm Thickness

Product Details:

Place of Origin:	ShenZhen
Brand Name:	PY
Certification:	ISO9001
Model Number:	PCB

Payment & Shipping Terms:

Minimum Order Quantity:	1PCS
Price:	0.1-1USD
Packaging Details:	Vacuum packing, high quality carton
Delivery Time:	5-10 work days
Payment Terms:	T/T
Supply Ability:	Ten thousand square meters per month

Contact Now

Color:

Green,Red,Black,Yellow,White,Blue

Number Of Plies:

2-4-6-8-10-12-16-20-22-28 Layer

Copper Thickness::

1-4oz

Base Material::

FR4 ,Rogers , Aluminum ,Hight TG

Board Thickness::

0.6～1.0～1.2～1.6～2.0～2.5～3.0～3.2mm

Place Of Origin::

Guangdong, China (Mainland)

Surface Finishing::

HASL(lead Free) / Immersion Gold /osp / Immersion Tin/Immersion Silver

Min. Hole Size:

3mil

Service:

OEM Services Provided,PCB/Components Sourcing/Soldering/Programming/Testing..,One-stop Turnkey Service,One Stop Turnkey Service,PCBA

Surface Finishing:

HASL,ENIG,OSP,HASL Lead Free,spray Tin

Application:

Electronics Device,ru 94v0 Pcb Printed Circuit Board,Consumer Electronics,rigid Fpc,mobile Usb Charger

High Light:

FR4 Pcb Prototype Board

3.0mm Thickness Pcb Prototype Board

4oz Flexible Circuit Board

Flexible PCB FPC Rigid Flexible PCB OEM RoHS Rigid-Flex Board

Advantages

1. PCB factory directly
2. Comprehensive quality control system
3. Competitive price
4. Quick turn delivery time from 48hours.
5. Certificates (ISO/UL E354810/RoHS)
6. 10 years experience in exporting service
7. No MOQ/MOV.
8. High quality. Strict through the AOI(Automated Optical Inspection), QA/QC, flying porbe ,Etesting, etc

Capability

High precision prototype

PCB bulk production

Max Layers

1-28 layers

1-14 layers

MIN Line width(mil)

3mil

4mil

MIN Line space(mil)

3mil

4mil

Min via (mechanical drilling)

Board thickness≤1.2mm

0.15mm

0.2mm

Board thickness≤2.5mm

0.2mm

0.3mm

Board thickness＞2.5mm

Aspect Ration≤13:1

Aspect Ration

Aspect Ration≤13:1

Board thickness

MAX

8mm

7mm

MIN

2 layers:0.2mm;4 layers:0.35mm;6 layers:0.55mm;8 layers:0.7mm;10 layers:0.9mm

2 layers:0.2mm;4 layers:0.4mm;6 layers:0.6mm;8layers:0.8mm

MAX Board size

610*1200mm

Max copper thickness

0.5-6oz

Immersion Gold/
Gold Plated Thickness

Immersion Gold:Au,1—8u”
Gold finger:Au,1—150u”
Gold Plated:Au,1—150u”
Nickel Plated :50—500u”

Hole copper thick

25um 1mil

Tolerance

Board thickness

Board thickness≤1.0mm:+/-0.1mm
1.0mm<Board thickness≤2.0mm:+/-10%
Board thickness>2.0mm:+/-8%

Outline Tolerance

≤100mm:+/-0.1mm
100< ≤300mm:+/-0.15mm
>300mm:+/-0.2mm

≤100mm:+/-0.13mm
100< ≤300mm:+/-0.15mm
>300mm:+/-0.2mm

Impedance

±10%

MIN Solder mask bridge

　0.08mm

　0.10mm

Plugging Vias capability

　0.25mm--0.60mm

　0.70mm--1.00mm
