3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board

3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board

  • 3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board
  • 3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board
  • 3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board
3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board
Product Details:
Place of Origin: ShenZhen
Brand Name: PY
Certification: ISO9001
Model Number: PCB
Payment & Shipping Terms:
Minimum Order Quantity: 1PCS
Price: 0.1-1USD
Packaging Details: Vacuum packing, high quality carton
Delivery Time: 5-10 work days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: Ten thousand square meters per month
Contact Now
Detailed Product Description
Color: Black,Yellow,Blue Number Of Plies: 4-6-8-10 Layer
Copper Thickness:: 6oz Base Material:: FR4 ,Hight TG
Board Thickness:: 0.6-3.2mm Place Of Origin:: Guangdong, China (Mainland)
Service: OEM Services Provided,PCB/PCBA
High Light:

6oz Flexible Circuit Board

,

3.2mm Flex Pcb Assembly

,

6oz Flex Pcb Assembly

3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board





Advantages


1. PCB factory directly
2. Comprehensive quality control system
3. Competitive price
4. Quick turn delivery time from 48hours.
5. Certificates (ISO/UL E354810/RoHS)
6. 10 years experience in exporting service
7. No MOQ/MOV.
8. High quality. Strict through the AOI(Automated Optical Inspection), QA/QC, flying porbe ,Etesting, etc





  High precision prototype PCB bulk production
Max Layers 1-28 layers 1-14 layers
MIN Line width(mil) 3mil 4mil
MIN Line space(mil) 3mil 4mil
Min via (mechanical drilling) Board thickness≤1.2mm 0.15mm 0.2mm
Board thickness≤2.5mm 0.2mm 0.3mm
Board thickness>2.5mm Aspect Ration≤13:1 Aspect Ration≤13:1
Aspect Ration Aspect Ration≤13:1 Aspect Ration≤13:1
Board thickness MAX 8mm 7mm
MIN 2 layers:0.2mm;4 layers:0.35mm;6 layers:0.55mm;8 layers:0.7mm;10 layers:0.9mm 2 layers:0.2mm;4 layers:0.4mm;6 layers:0.6mm;8layers:0.8mm
MAX Board size 610*1200mm 610*1200mm
Max copper thickness 0.5-6oz 0.5-6oz
Immersion Gold/
Gold Plated Thickness
Immersion Gold:Au,1—8u”
Gold finger:Au,1—150u”
Gold Plated:Au,1—150u”
Nickel Plated :50—500u”

Hole copper thick 25um 1mil 25um 1mil
Tolerance Board thickness Board thickness≤1.0mm:+/-0.1mm
1.0mm<Board thickness≤2.0mm:+/-10%
Board thickness>2.0mm:+/-8%
Board thickness≤1.0mm:+/-0.1mm
1.0mm<Board thickness≤2.0mm:+/-10%
Board thickness>2.0mm:+/-8%
Outline Tolerance ≤100mm:+/-0.1mm
100< ≤300mm:+/-0.15mm
>300mm:+/-0.2mm
≤100mm:+/-0.13mm
100< ≤300mm:+/-0.15mm
>300mm:+/-0.2mm
Impedance ±10% ±10%
MIN Solder mask bridge  0.08mm  0.10mm
Plugging Vias capability  0.25mm--0.60mm  0.70mm--1.00mm





Applications:


Communications
Traditional telecommunication equipment, FTTP, VOIP, multimedia services, data networking and IT infrastructure products, wireless infrastructure products, power amplifiers, splitters and combiners, high power transistors, etc.

Computer Peripherals
High end printers, cable modem, wireless routers, IP telephones, consumer and office products, banking system etc.

Consumer
Computers, televisions, cameras, digital video recorders (DVR), handheld products, LED, etc.

Automotive
Passenger safety systems, engine control systems, air bags, traction control products, etc.

High End Computing and Storage
High performance computer and server, mainframe system and storage equipment, memory, etc.

Industry


Power supply, main control panel, monitor, CCTV products,automotive control equipment, industry robot, access control products etc

Medical
Magnetic resonance imaging (MRI), computed tomography (CT), emergency response defibrillation units, patient monitoring, implantable devices, robotic surgery systems, biometrics and diagnostic equipment, etc.

Military
Satellite, radar, airplane, control unit, communication equipment .etc.

Test & Measurement
Power meters, electricity tester, thermal tester, light tester, network tester, gas and oil tester, infrared products, semi-conductor test equipment, DUT and probe cards, wafer inspection systems, etc.





3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board 0

3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board 1

3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board 2





3.2mm Quick turn Flex Pcb Assembly 6oz Flexible Circuit Board 3

1. Are you headquarter or branch?
We are Ping you headquarter and factory.



2. Can I ask for samples before placing an order?
Yes, we welcome sample order to test and check quality,Miced samles are acceptable.



3. How to be your overseas agent?
Depends which area you are located in,Every conuntries are different.



4. What need I do if I want to pint my own logo?
First, please send us your logo flie in high resolution, We will make some drafts

for your reference to confirm the position and size of your logo.Next we will 1-2

samples for you to check the actual effect.Finally the formal production will start

after the sample confrimed .



5. Can you ship the goods to my agent or shipping forwarder in China?
Yes,We can,please kindly contact with your agent in advance and us detailed address.



6. How can you solve the problem if receive the defective goods?
Will check all the products before delivery,Please kindly provide the pictures or

video and send back to china or our local agent,After they checking,will replace new

or fix free.
