0.6mm Multilayer Printed Circuit Board Electronic PCB Lead Free

Place of Origin ShenZhen
Brand Name PY
Certification ISO9001
Model Number PCB
Minimum Order Quantity 1PCS
Price USD: 0.1-1\PCS
Packaging Details Vacuum packing, high quality carton
Delivery Time 5-10 work days
Payment Terms T/T, L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability Ten thousand square meters per month

Contact me for free samples and coupons.

WhatsApp:0086 18588475571

Wechat: 0086 18588475571

skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Color Green Number Of Plies 6-8 Layer
Copper Thickness 1-4oz Base Material FR4 Hight TG
Board Thickness 0.6mm Place Of Origin Guangdong, China (Mainland)
Min. Hole Size 3mil
High Light

0.6mm Multilayer Printed Circuit Board

,

0.6mm Electronic PCB

,

4oz Multilayer Printed Circuit Board

Leave a Message
Product Description

0.6mm Multilayer Printed Circuit Board Electronic PCB Lead Free



company introduction



Ping You Industrial Co.,Ltd
Ping You Industrial Co.,Ltd is a professional and reliable one-stop PCB solutions provider for customers specialized in manufacturing quick turn prototypes and small volumes.Topfast is responsible for overseas business development.With high quality and on-time delivery products we won the market's wide acclaim. We will continue to focus on customer satisfaction, along with "high quality "and "fast delivery", we will become a PCB service provider worthy of customer trust.



Product Parameter



  High precision prototype PCB bulk production
Max Layers 6 layers 8layers
MIN Line width(mil) 3mil 4mil
MIN Line space(mil) 3mil 4mil
Min via (mechanical drilling) Board thickness≤1.2mm 0.15mm 0.2mm
Board thickness≤2.5mm 0.2mm 0.3mm
Board thickness>2.5mm Aspect Ration≤13:1 Aspect Ration≤13:1
Aspect Ration Aspect Ration≤13:1 Aspect Ration≤13:1
Board thickness MAX 8mm 7mm
MIN 6 layers:0.55mm;8 layers:0.7mm; 6 layers:0.6mm;8layers:0.8mm
MAX Board size 610*1200mm 610*1200mm
Max copper thickness 0.5-6oz 0.5-6oz
Immersion Gold/
Gold Plated Thickness

Gold Plated:Au,1—150u”
Nickel Plated :50—500u”

Hole copper thick 25um 1mil 25um 1mil
Tolerance Board thickness Board thickness≤1.0mm:+/-0.1mm
1.0mm<Board
Board thickness≤1.0mm:+/-0.1mm
1.0mm<Board
Outline Tolerance ≤100mm:+/-0.1mm
100< ≤300mm:+/-0.15mm
≤100mm:+/-0.13mm
100< ≤300mm:+/-0.15mm
Impedance ±10% ±10%
MIN Solder mask bridge  0.08mm  0.10mm
Plugging Vias capability  0.25mm--0.60mm  0.70mm--1.00mm





Applications:


Communications
Traditional telecommunication equipment, FTTP, VOIP, multimedia services, data networking and IT infrastructure products, wireless infrastructure products, power amplifiers, splitters and combiners, high power transistors, etc.

Computer Peripherals
High end printers, cable modem, wireless routers, IP telephones, consumer and office products, banking system etc.

Consumer
Computers, televisions, cameras, digital video recorders (DVR), handheld products, LED, etc.

Automotive
Passenger safety systems, engine control systems, air bags, traction control products, etc.

High End Computing and Storage
High performance computer and server, mainframe system and storage equipment, memory, etc.

Industry


Power supply, main control panel, monitor, CCTV products,automotive control equipment, industry robot, access control products etc

Medical
Magnetic resonance imaging (MRI), computed tomography (CT), emergency response defibrillation units, patient monitoring, implantable devices, robotic surgery systems, biometrics and diagnostic equipment, etc.

Military
Satellite, radar, airplane, control unit, communication equipment .etc.

Test & Measurement
Power meters, electricity tester, thermal tester, light tester, network tester, gas and oil tester, infrared products, semi-conductor test equipment, DUT and probe cards, wafer inspection systems, etc.





Assemblability



PCB products are not only convenient for various components to be standardized assembly, but also can be automated, large-scale mass production.At the same time, PCB and various components assembly parts can also be assembled into larger components, systems, until the complete machine.

Maintainability.Because PCB products and various component assembly parts are standardized in design and mass production, these parts are also standardized.Therefore, once the system fails, it can be replaced quickly, conveniently and flexibly, and the work of the system can be restored quickly.There are, of course, many more examples.Such as miniaturization of the system, light weight, signal transmission speed and so on.

0.6mm Multilayer Printed Circuit Board Electronic PCB Lead Free 0

0.6mm Multilayer Printed Circuit Board Electronic PCB Lead Free 1

0.6mm Multilayer Printed Circuit Board Electronic PCB Lead Free 2

RFQ



1. Are you headquarter or branch?

We are Ping you headquarter and factory.







2. Can I ask for samples before placing an order?

Yes, we welcome sample order to test and check quality,Miced samles are acceptable.







3. How to be your overseas agent?

Depends which area you are located in,Every conuntries are different.







4. What need I do if I want to pint my own logo?

First, please send us your logo flie in high resolution, We will make some drafts for your reference to confirm the position and size of your logo.Next we will 1-2 samples for you to check the actual effect.Finally the formal production will start after the sample confrimed .







5. Can you ship the goods to my agent or shipping forwarder in China?

Yes,We can,please kindly contact with your agent in advance and us detailed address.







6. How can you solve the problem if receive the defective goods?



Will check all the products before delivery,Please kindly provide the pictures or video and send back to china or our local agent,After they checking,will replace new or fix free.



0.6mm Multilayer Printed Circuit Board Electronic PCB Lead Free 3

0.6mm Multilayer Printed Circuit Board Electronic PCB Lead Free 4

0.6mm Multilayer Printed Circuit Board Electronic PCB Lead Free 5
